We provide remote Cabinet Vision engineering that translates design intent into production reality. Our focus is on assembly logic, hardware coordination, part structure, and CNC readiness — so your shop receives models that are accurate, predictable, and manufacturable with fewer revisions and less rework.
Assembly logic aligned with your construction method
Hardware coordination (hinges, glides, line boring, clearances)
Consistent part naming, grain direction, and machining intent
Conflict resolution before CNC output
Models structured for clean shop handoff and repeatability
Engineering built for manufacturing
Cabinet Vision models in cabinet mode and closet mode
Panel structure, reveals, and tolerances
Hardware placement and drilling logic
Material definitions and thickness consistency
File organization for your shop’s workflow
Preparation for S2M nesting and CNC output
What we engineer
Our process
Step 1 — Share standards
Send your PDFs, shop standards, sample CVJ files, hardware preferences, and any rules your team already follows in Cabinet Vision.
Step 2 — Build in Cabinet Vision
We engineer the job using your conventions, verify clearances, coordinate hardware, and structure parts so they behave correctly in manufacturing.
Step 3 — Deliver CNC-ready package
You receive an organized CVJ file, coordinated drawings, and any scoped outputs needed for S2M optimization or CNC production.
Kitchens, baths, and built-ins
Custom closets and storage systems
Commercial casework and hospitality millwork
Reception desks and retail displays
Custom panels, trims, and special details
Cabinets, closets, and millwork we support
Frequently Asked Questions
Do you deliver the CVJ file?
Yes — a structured, production-ready CVJ file is always included.
Can you match our shop standards?
Yes. Send a sample job or standards sheet and we will align our engineering to your conventions.
Do you coordinate hardware?
Yes — we model hinges, glides, line boring, and clearances based on your preferred hardware system.
Do you provide CNC-ready outputs?
Yes — we can prepare models and documentation that integrate with your CNC workflow when included in scope.
Upload your plans and specify your preferred deliverables (CVJ, drawings, S2M optimization, or CNC-ready output). We will clarify scope and provide a clear timeline.
Request a quote
No obligation — scope is confirmed before any work begins.
